Solid Epoxy Resin (Medium and high-Molecular Weight, Bisphenol A type )

It is a type of colorless or yellowish solid epoxy resin, widely used in many fields such as coating, paint and anticorrosion.

Type No Brand Epoxy equivalent (g/mol) Hydrolysable chlorine, wt%≤ Softening point (℃) Soluble viscosity (℃) Melting Viscosity (℃) Volatile, wt%≤ Color ( Pt-Co )≤
1 CYD-011 450～500 0.1 60～70 D~F — 0.6 35
2 CYD-011Y 450～500 0.1 60～70 D~F — 0.6 60
3 CYD-011D 470～480 0.1 60～70 D~F — 0.6 35
4 CYD-011A 530～570 0.15 65~75 G~J — 0.6 35
5 CYD-012 600～700 0.1 75~85 — 1000~2000 0.6 35
6 CYD-013 700～800 0.15 85~95 — 1500～3000 0.6 30
7 CYD-013L 900～1050 0.1 88~97 — — 0.6 100
8 CYD-014 900～1000 0.1 91～102 Q~V — 0.6 30
9 CYD-014U 710～875 0.1 88～96 一 1500~4500 0.6 30
10 CYD-014UY 710～875 0.1 88~96 L~Q — 0.6 60
11 CYD-014UL 700～760 0.1 84~90 一 1000～2500 0.6 30
12 CYD-014UH 850～900 0.1 91～100 Q~R — 0.6 30
13 CYD-014UD 815～835 0.1 88~92 L~Q — 0.6 30
14 CYD-014A 710～800 0.1 88~92 L~Q — 0.6 30
15 CYD-014T 750～810 0.1 92~100 L~Q — 0.6 30
16 CYD-014F 710~875 0.1 88~105 L~S — 0.6 30
17 CYD-017 1750～2100 0.1 117~127 Y~Z1 — 0.6 60
18 CYD-019 2400～3300 0.1 130～145 Z3~Z5 — 0.6 60
19 CYD-020N 4000～6000 0.1 135~150 Z5~Z6 — 0.6 200

*Remark: Epoxy Equivalent 1g/mol=1g/eq

Liquid Epoxy Resin (Bisphenol A type)

It is a type of colorless or yellowish liquid epoxy resin. Due to its special properties, it is mainly used in coating, adhesive, anticorrosion, electric insulation, laminated plates and potting fields. It is also used as the raw material for the production of high-end epoxy resin.

SPECS OF LIQUID EPOXY RESIN - CYD SERIES

Type No Brand Epoxy equivalent (g/mol) Hydrolysable chlorine wt%≤ Viscosity (mPa.s25℃) Volatile wt%≤ Color Pt-Co≤ Color Gardner≤
1 CYD-127 180～190 0.1 8000～11000 0.2 60 –
2 CYD-127E 180～186 0.035 10000～13000 0.2 60 –
3 CYD-128 184～194 0.1 11000～14000 0.2 60 –
4 CYD-128D 186～190 0.035 12000～16000 0.2 60 –
5 CYD-128E 184～194 0.0200～0.0400 11000～14000 0.2 60 –
6 CYD-128M 186～190 0.15 12500～14500 0.05 20 –
7 CYD-128Y 187～193 0.1 12000～15000 0.2 40 –
8 CYD-128YL 185～189 0.03 10000～16000 0.05 20 –
9 CYD-128S 205～225 1.8000～2.4000 19000～24000 0.2 60 –
10 CYD-128F 186～190 0.05 12500～14000 0.2 40 –
11 CYD-188 187～189 0.028 12500～14300 0.2 30 –
12 CYD-134 230～270 0.1 0.3 1
13 CYD-115 180～194 0.1 700～1100 10 1
14 CYD-115C 195～215 1.7000～2.0000 800～1600 12 1

SPECS OF LIQUID EPOXY RESIN- E SERIES

type No Brand Epoxy equivalent (g/mol) Hydrolysable chlorine wt%≤ Inorganic chlorine, wt%≤ Softening point (℃) Volatile wt%≤ Color Gardner≤
1 E-44 210～240 0.3 0.018 14～22 0.6 1
2 E-44(I1) 215～240 0.3 0.018 15～23 0.6 1
3 E-42 230～280 0.3 0.01 21～27 0.6 1
4 E-39D 240～256 0.04 0.002 24～29 0.5 1
